Please note: This S300 device updated to latest S800 testbox which more powerful and price close, so S300 will stop selling soon, so if you want to buy S300 testbox we advice to buy S800 device from our website.
This is a 6in1 S300 test box that supports screens for iPhone Samsung Huawei Oppo Vivo and Xiaomi. Update to 2022-12-31, it has 271 flex cables that support 567 different models.
- It includes 21 flex cables that support 21 models for iPhone LCDs from 6g to 13 (Not 13 Pro and 13 Pro Max)
- It includes 71 flex cables that support 128 different models for Huawei
- It includes 46 flex cables that support 57 different models for Samsung screens
- It includes 44 flex cables that support 167 models for Oppo
- It includes 48 flex cables that support 133 models for Vivo
- It includes 41 flex cables that support 61 models for Xiaomi
Reminder: We understand you do not need some of the flex cables, if buy single that is expensive, if buy bundle you do not need some which is a waste, so we add an option S300 box + 100pcs any of flex cables, if you choose this option please leave notes and tell us the 100pcs flex cables you want so we can package right flex cables for you.
Details see attached below:
System version after 2022-11-07 there is an important update that system file for Oppo Vivo and Xiaomi will be put in USB disk to save storage to have more useful functions for S300 device. To be short, after updating this version, the device includes system files for iPhone Samsung Huawei only, if you want to test screens for Oppo vivo and xiaomi as well then you need to connect USB disk when testing these screens, if only need to test screens for iPhone Samsung Huawei then no need to connect USB disk.
This S300 supports LCD Test, test 3D, test touch only, Recover True Tone, compare with S200, its advantages as below:
- Its power on speed faster (S200 take 10-20s, S300 less than 4s)
- Model changing reading speed faster (S200 take 5-30s depending on models, S300 take 1s)
- Truetone reading faster (S200 take 10s, S300 less than 3s)
- System update speed faster (S200 take around 25 minutes, S300 less than 10 minutes)
Faster means you can test more LCDs at the same time.
2. More accurate
- It has an extra display on test box which you can see the screen voltage and currency itself, from this function you will be able to find whether screen get some problem
- Market many people sell TFT LCD as OLED screens, as their currency is different so you will be able to find whether they are selling fake OLED while it is a TFT screen.
- S300 can test touch panel only which means if the inner LCD broke you can switch to the “tp test only” model and test whether its touch panel is able to recycle. And still, as touch panel testing only model you can identify 8 Plus and below from Incell structure to other qualities.
- When testing if the flex cable is not plugged well the display will have error info so we know what causes it.
- When updating the system some people failed, before they don’t know why it happened, now there is error info, like USB failed, file issue, or something.
- And there are more functions you can find from our S300
- Charge adapter
- Type-C data line
- USB disk (more than 20% of customers update files due to their damaged USB or issue USB disk, so we prepare a USB with you for future updates)
- Baseboard for S300 (They look similar but they are different, S200 on baseboard write S200, while S300 write S300)
- Flex cables depend on what you have chosen when buying
If you bought an S300 box before, you can update the system to support all these models for iPhone Huawei and Samsung Screens, just buying a flex cable set is fine.
Below is how to update:
- Within 7 days from the day you buy the product, if the device does not work fine, it will be detected and confirmed by our After-sales Service Center, and you can enjoy the service of returning or replacing goods for free.
- Within 8-15 days from the day you buy the product, if the device does not work fine, it will be detected and confirmed by our After-sales Service Center, and you can enjoy the replace or repair service for free
- Within 16-365 days from the day you buy the product, if the device does not work fine, it will be detected and confirmed by our After-sales Service Center, and you can enjoy the repair service for free
- machine hurt caused by misuse or improper storage or disassemble or repair.
- Tear up altered labels and security marks.
- Warranty is expired after 1 year.
- machine hurt caused by not using our charge adapter and data line.
- Please don’t disassemble, repair or modify this product by yourself
- Please don’t expose this product to rain or moisture
- Please don’t expose the product to a heat source or high-temperature environment, avoid storing it in direct sunlight
